DIY heat shield - for under £20

Discussion in 'A3/S3 Forum (8L Chassis)' started by Piester, Feb 23, 2011.

  1. Piester
    Offline

    Piester Member

    Joined:
    Oct 30, 2009
    Messages:
    90
    Likes Received:
    2
    So this all came about after I fitted my a Badger5 3" TIP and JR filter. Having pulled out the old airbox I could see that the MAF and filter were going to be bouncing about all over the place, so figured I needed something to secure it, stopping the vibrations destroying the MAF. That and obviously something to stop the heat soak.

    I looked at a few on the web but decided I wanted something a little more substantial yet still pretty simple as I'm a bit of a spanner with a spanner. Don't get me wrong, this is officially amateur hour.

    Anyway, I popped down to Homebase and picked up the following...

    Materials:
    • Steel sheet - 100cm x 50cm x 0.0055cm - £16
    • 2 x nuts & bolts - 4mm - £0.85
    Tools:
    • Tin snips - £17
    • Rivet gun - £16
    • Drill - 4mm & 6mm drill bits
    The design is all one piece of steel to keep it fairly fool proof, cut to the template below and riveted together. It's a fairly tight fit which is what I was going for so that it doesn't rattle around. It also gives as much room around the filter as possible, so shouldn't be too restrictive.
    [​IMG]

    Before first fitting... needed to be trimmed down a couple of inches in length as it just wouldn't fit. Not as easy as it sounds.

    [​IMG]

    Fitted...

    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]

    I used one of the airbox fitting screws to secure it against the wheel arch, as well as the rubber ring from the lid of the airbox to space the filter from the heat shield. Having just thought about it, it would probably be better used to space the MAF from the heat shield. Must remember that.

    What would I do differently?
    • Potentially use aluminium instead of steel as it would be lighter and easier to cut/bend. Unfortunately that's all Homebase had on the day.
    • Reduce the height by about 10mm as mine makes an indentation on the bonnet lining. It's a tight fit at least!
    • Make the tabs larger which would make them easier to bend. These were a real ball ache with the thickness of the steel and fairly little leverage.
    • Find a better tool to cut the MAF hole out - that took bloody ages to get a decent circle with those tin snips.
    The adjustments above have been made to the template. Mine looks a little rough as I had to make adjustments as I went, which was a pain once everything had been bent into shape. Might also find some PVC edge trim to finish up the sharp (now slightly scrappy) edges.

    All in all I'm pretty happy with it, certainly does the job. If you have the tools already, it's a steal at £17.

    Next up is a cold air feed. Any suggestions?

    Any thoughts, comments, amendments on the design? What has everyone else done? Answers on a postcard.

    Cheers,
    Geoff
    #1
    Empty and Drewvic like this.
  2. [Dave B]
    Online

    [Dave B] Rrrrrrrr-tech

    Joined:
    Jan 3, 2003
    Messages:
    1,995
    Likes Received:
    111
    That looks great mate, well done!
    #2
  3. bez101
    Offline

    bez101 Yorkshire & Humber Rep.

    Joined:
    Jul 8, 2008
    Messages:
    8,735
    Likes Received:
    494
    looks good
    1 thing tho
    paint it will look even better
    #3
  4. nwmlarge
    Offline

    nwmlarge flat out

    Joined:
    Feb 15, 2010
    Messages:
    219
    Likes Received:
    1
    that would look awesome in the matt black like the engine covers
    #4
  5. badger5
    Offline

    badger5 RIP S3dave Site Sponsor

    Joined:
    May 28, 2004
    Messages:
    7,282
    Likes Received:
    673
    very well done fella.. nice one
    #5
  6. Piester
    Offline

    Piester Member

    Joined:
    Oct 30, 2009
    Messages:
    90
    Likes Received:
    2
    Cheers for the comments.

    Actually I had thought about spraying it black as not only would it look the nuts and blend in a bit more, but would also give it a little protection against the elements.

    However, would spraying it black not make it absorb heat rather than reflect it, or are we talking about low enough temperatures for it not to matter?
    #6
  7. badger5
    Offline

    badger5 RIP S3dave Site Sponsor

    Joined:
    May 28, 2004
    Messages:
    7,282
    Likes Received:
    673
    dont worry about the colour of the paint...
    #7
  8. DaveA3
    Offline

    DaveA3 Audi A-Trizzle!

    Joined:
    Feb 25, 2010
    Messages:
    2,374
    Likes Received:
    14
    wow lovely job mate!
    #8
  9. fran-s3
    Offline

    fran-s3 Active Member

    Joined:
    Jan 29, 2008
    Messages:
    1,103
    Likes Received:
    1
    Wow looks awesome! Wish I was as clever and handy enough to make one of those....
    #9
  10. coyle
    Offline

    coyle From Show... to GO

    Joined:
    Nov 16, 2010
    Messages:
    435
    Likes Received:
    1
    brilliant! i'll be making this in the morning!

    did you draw around the filter for the circle hole size?
    #10
  11. shanejess
    Online

    shanejess Guest

    well done looks good, i wish i could put my hand to stuff like that.
    #11
  12. coyle
    Offline

    coyle From Show... to GO

    Joined:
    Nov 16, 2010
    Messages:
    435
    Likes Received:
    1
    also, how did you get the steel to fold so well, did you score it to weaken it at the joint? or just fold up around a spirit level, or something similar with a sharp edge?
    #12
  13. barters3
    Offline

    barters3 Member

    Joined:
    May 21, 2008
    Messages:
    438
    Likes Received:
    0
    i was going to design something like this when iv got a badger5 tip and jetex. however youve done the hard work, nice one. Im going to make it out of card following your design and then tweak if necessary.... iv got some spare satin black sat here so i think ill paint mine when its done.
    #13
  14. s3_kev
    Offline

    s3_kev Stage2'd!!!!!!

    Joined:
    Feb 17, 2008
    Messages:
    1,999
    Likes Received:
    18
    after seeing your own coment of being a 'spanner' i thought oh no here we go it will be rubbish, but you stand me corrected thats actually a very good effort, well done
    #14
  15. s3dave
    Offline

    s3dave TFSI Hybrid

    Joined:
    Nov 11, 2009
    Messages:
    10,120
    Likes Received:
    728
    Nice effort, i do them in ali with 2 fixing points, 1 down by the battery, well done on the folds with no press...
    #15
  16. DJ_Troopa
    Offline

    DJ_Troopa K1 Driver

    Joined:
    Oct 30, 2008
    Messages:
    1,741
    Likes Received:
    13
    Brilliant DIY there! I got the Jabba heat shield route for myself though a month back. Yours would be better if it was longer so it covered the whole length of the air filter.
    #16
  17. coyle
    Offline

    coyle From Show... to GO

    Joined:
    Nov 16, 2010
    Messages:
    435
    Likes Received:
    1
    Troopa, his did cover the whole length, but it was cut down due to fitting issues
    #17
  18. damo.h
    Offline

    damo.h DVLA Say it's Black

    Joined:
    Feb 9, 2010
    Messages:
    3,608
    Likes Received:
    64
    Good skills dude.
    #18
  19. coyle
    Offline

    coyle From Show... to GO

    Joined:
    Nov 16, 2010
    Messages:
    435
    Likes Received:
    1
    Last edited: Feb 23, 2011
    #19
  20. S3BN_H
    Offline

    S3BN_H Member

    Joined:
    Dec 19, 2010
    Messages:
    45
    Likes Received:
    0
    looks great mate,, make a few and sell them !!
    #20
  21. cecilthesausage
    Offline

    cecilthesausage ...It's Never Finished...

    Joined:
    Jul 20, 2010
    Messages:
    933
    Likes Received:
    111
    That riveter will do the trick coyle
    #21
  22. coyle
    Offline

    coyle From Show... to GO

    Joined:
    Nov 16, 2010
    Messages:
    435
    Likes Received:
    1
    nice one dude, i'll get everything tomorrow, and have a go.
    going to make it from cardboard 1st, make sure im happy with it, then go for it
    #22
  23. s3 man
    Offline

    s3 man Member

    Joined:
    Feb 15, 2010
    Messages:
    105
    Likes Received:
    0
    Hi piester is the template you have wrote down before or after the things you said you would do different at the end of your post?
    #23
  24. J B
    Offline

    J B Member

    Joined:
    Dec 7, 2008
    Messages:
    139
    Likes Received:
    0
    Thats exactly what I needed, something to keep me busy at the weekend, had been thinking about this and grabbed some cardboard to make a mock up then you post this! Top bombing :thumbsup:
    #24
  25. s3 Hoggy
    Offline

    s3 Hoggy Whats going on???

    Joined:
    Apr 4, 2009
    Messages:
    1,656
    Likes Received:
    95
    This looks great! I don't have a badger5 tip or a jetex filter but still feel the urge to just make a heatshield!!!
    Last edited: Feb 24, 2011
    #25
  26. sportstractor
    Offline

    sportstractor Chugger

    Joined:
    Nov 25, 2009
    Messages:
    2,715
    Likes Received:
    31
    got to admit i was expecting something made of ply and coated with tin foil! pmsl

    But im seriously impressed, you have all the DIYers with 3" mafs coming out of their holes... very inspirational.

    Maybe a competition for the most elabourate heatshield? :p
    #26
  27. coyle
    Offline

    coyle From Show... to GO

    Joined:
    Nov 16, 2010
    Messages:
    435
    Likes Received:
    1
    could make a perspex lid ;)
    #27
  28. antnee
    Offline

    antnee Member

    Joined:
    Aug 31, 2009
    Messages:
    97
    Likes Received:
    1
    Looks good, might have to make myself one! Might go one step further and make it from CF though :hubbahubba:

    Is there a good place to get a CAI feed from?
    #28
  29. DaveA3
    Offline

    DaveA3 Audi A-Trizzle!

    Joined:
    Feb 25, 2010
    Messages:
    2,374
    Likes Received:
    14
    could get some carbon wrap around the sheet steel. would look great
    #29
  30. Westy
    Offline

    Westy Double Dark Side! Diesel & 8P

    Joined:
    Dec 2, 2008
    Messages:
    17,296
    Likes Received:
    969
    Nice work, you have got the cogs going round in my head now too ;)
    #30
  31. Piester
    Offline

    Piester Member

    Joined:
    Oct 30, 2009
    Messages:
    90
    Likes Received:
    2
    It's really not that hard, honestly. This is the first thing like this I've made and whilst it took me a while, that's mainly because I was trying to figure it from scratch.

    Draw around the MAF, as that's what goes through the hole. If you end up cutting it slightly bigger, it's not the end of the world as the two screws fastening the MAF to the heat shield will stop it rattling around.

    I did score the outside of the edges of the tabs with a standly knife, but not too much as I didn't want it to split. To bend I just used two off cuts of the steel to get it nice and even. Only the tabs really posed a problem as they were so short on mine.

    Exactly right. Whilst my dimensions worked for me, that's based on how I fitted the TIP. Given that the TIP is fairly adjustable being in three bits, it shouldn't be too different but definitely do a template first. Use card as well, not paper like I did. Whilst it looks like it fits on the paper template, it's a different story once it's solid steel.

    I'd actually made a bracket to use the battery fixing point to give it the extra stability, but the whole thing is such a tight fit I decided there wasn't any need to in the end. No point over complicating things.

    That's what I thought but it didn't fit as a straight rectangular box and whilst I could have tapered it in at a similar angle to the filter, I thought it would only be more restrictive. Also as it's squared off, it follows the line of the battery cover which keeps it nice and neat.

    That's pretty much exactly the same as the one I bought.

    Can't be arsed. The template is there though for anyone that wants it.

    I made a few rough amends to the measurements when it was finished based on the issues I had, but would definitely recommend making a card template first and a seeing how it fits the way you've set up your TIP.

    This is what I want to know. I've seen somewhere that someone had flexible ducting pipe (as below) going down under the headlight. Anybody got any pictures or ideas?

    NTCDUCTING.COM -Heating and Ventilation Ducting - Industrial Ducting- Flexible Ducting Manufacturer

    Cheers again for all the comments. Definitely worth giving it a go if your bored one day.

    Again if anyone has any changes to the template, PM me and I'll send you the powerpoint I made it on, or if you just want it to print I've got it on a PDF.
    #31
  32. Piester
    Offline

    Piester Member

    Joined:
    Oct 30, 2009
    Messages:
    90
    Likes Received:
    2
    Crikey, that was a long reply!
    #32
  33. s3dave
    Offline

    s3dave TFSI Hybrid

    Joined:
    Nov 11, 2009
    Messages:
    10,120
    Likes Received:
    728
    I can cut some 2500mm x 1250mm aluminium sheet down to the overall cut size at cost, if there is enough interest
    should be no more than £10 delivered....
    #33
  34. JamJay
    Offline

    JamJay Member

    Joined:
    Oct 29, 2010
    Messages:
    188
    Likes Received:
    2
    Fantastic! It looks a lot like my old Neuspeed shield which I can confirm does not fit with Badger 5 TIP even with 1" trimmed off of each end of the top 90degree bend. The problem with the Neuspeed was that it wanted to sit too far backwards to meet the mounting points which meant the TIP needed to be pushed back so far that it raised and kinked. The Jabba one looked like the TIP slides into the shield rather than bolts to it which will be better but I like the idea of securing the MAF to something so I might make a version of what you have done but have it sitting further forwards with the mount points moved further back.
    #34
  35. badger5
    Offline

    badger5 RIP S3dave Site Sponsor

    Joined:
    May 28, 2004
    Messages:
    7,282
    Likes Received:
    673
    if Neuspeed can fit on std intake or silicon one, why would'nt it fit with my 3inch, which fits on std airbox if you trim it accordingly?

    Neuspeed one is narrow tho, too narrow for the JR filter.. that I have seen
    #35
  36. s3dave
    Offline

    s3dave TFSI Hybrid

    Joined:
    Nov 11, 2009
    Messages:
    10,120
    Likes Received:
    728
    Yeah the neuspeed is oval.. and sits in on the shorter side
    #36
  37. fran-s3
    Offline

    fran-s3 Active Member

    Joined:
    Jan 29, 2008
    Messages:
    1,103
    Likes Received:
    1
    Anyone got a picture of the Jabba one? Can you confirm if it would fit with the JR filter?
    #37
  38. JamJay
    Offline

    JamJay Member

    Joined:
    Oct 29, 2010
    Messages:
    188
    Likes Received:
    2
    This I can't answer Bill but I would have had to make a right mess of your TIP to get it to fit. I trimmed 2" off as if was and any more than I'd been too close to the bend in the pipe so it was a non-started I'm afraid. The only other way I could have done this would be to trim the lower 90degree bend and make it very short. I moved the hoses at all angles on the ported joiner and still no luck, just doesn't fit I'm afraid.
    #38
  39. fran-s3
    Offline

    fran-s3 Active Member

    Joined:
    Jan 29, 2008
    Messages:
    1,103
    Likes Received:
    1
    Piester regarding the cold air feed, me and my friend did once manage to stuff a cold air feed down the hole in the side of the wing where the original hole is where the passenger wheel is... (well it's more of a triangle then a hole, gap thing) He had to take my wheel fender off and pointed the other end forwards so as to catch cold air above the passenger wheel.... I was trying to install a universal enclosed kit but it didn't work out (as the pipe kept collapsing on full acceleration because of the angle) Anyway the point is you can utilise that gap and get a cold air feed down there, means a very tight fit with the wheel fender/guard things as we struggled to put them back on - a lot of bending was needed but it was possible. I'll definitely be doing that when I get the JR filter.. and of course u can pull the cold air pipe out as much as you want so it's pointing right at the cone..... Not as good as the front of the bumper but the next best thing I think.
    #39
  40. JamJay
    Offline

    JamJay Member

    Joined:
    Oct 29, 2010
    Messages:
    188
    Likes Received:
    2
    How did you cut the hole for the MAF meter housing?
