Coming Home lights

Discussion in 'A4/A4 cabriolet/S4 forum(B6 chassis)' started by Paul @ Unit 9 Remaps, Mar 9, 2012.

  1. Paul @ Unit 9 Remaps
    Offline

    Paul @ Unit 9 Remaps Site Sponsor Site Sponsor

    Joined:
    Aug 10, 2009
    Messages:
    1,443
    Likes Received:
    29
    [Mar 9, 2012]
    Anyone tried this way on there B6.

    cominghomelights - Audi Retrofit

    ive read that you can do it by changing the switch etc, but this way seems so much easier.
    #1
  2. Ads

    Ads

    [Dec 25, 2014]

  3. Alan H
    Offline

    Alan H Need a V8 or Bi-Turbo.......

    Joined:
    Aug 14, 2010
    Messages:
    454
    Likes Received:
    7
    [Mar 9, 2012]
    That looks like a good retrofit. I would really like that function mine.

    Are you going to attempt it?

    Take some pics if you do!!
    #2
  4. AlexGSi2000
    Offline

    AlexGSi2000 Well-Known Member VCDS Map User

    Joined:
    Feb 14, 2012
    Messages:
    1,323
    Likes Received:
    163
    [Mar 9, 2012]
    Not sure, but I would expect the wiring to be different on the B6 A4 compared to the 8P A3.
    #3
  5. benjie
    Offline

    benjie Active Member

    Joined:
    Oct 10, 2009
    Messages:
    891
    Likes Received:
    138
    [Mar 9, 2012]
    It's not something to be enabled on the B6 like it is on the A3 8P. I have retrofitted it along with an auto-dimming interior mirror, wing mirrors and auto headlights. Quite complicated, but not hard. The auto-dimming mirror is needed to tell the coming home lights when to turn on.

    From that write up, I would imagine the coming home lights would come on whether it was light or dark - fine if that's what you're looking for, but will look to others like it's not working properly. Also, to follow that A3 thread, you would need to find out exactly what wires you are removing/replacing so as to do the same on the B6.
    #4
  6. Point_Audi
    Offline

    Point_Audi Vorsprung durch Technik Regional Rep VCDS Map User

    Joined:
    May 22, 2010
    Messages:
    907
    Likes Received:
    428
    [Mar 9, 2012]
    #5
  7. Alan H
    Offline

    Alan H Need a V8 or Bi-Turbo.......

    Joined:
    Aug 14, 2010
    Messages:
    454
    Likes Received:
    7
    [Mar 10, 2012]
    #6
  8. benjie
    Offline

    benjie Active Member

    Joined:
    Oct 10, 2009
    Messages:
    891
    Likes Received:
    138
    [Mar 10, 2012]
    From memory, that looks like the wiring I used in mine, an F module is £230+VAT from a dealer and once you enable it, you will have a permanent yellow warning light in your dash (where the miles to empty/mpg is) that looks similar to the symbol on the new switch shown in the pdf guide.
    #7
  9. NHN
    Offline

    NHN Retrofitter - Audi - VW - Skoda - Seat Site Sponsor VCDS Map User

    Joined:
    Jan 14, 2008
    Messages:
    27,510
    Likes Received:
    1,274
    [Mar 10, 2012]
    It was done on a B6 cab sometime back, problem is the lights are on during the day aswell, as no sensor to distinguish between the different light conditions, so expect some quirks for sure, not really a substitute for the complete system, installed a fair few proper systems & its great with auto lights etc.
    #8
